6.4 Transfer Procedure (Using a Communication Cable)
6-33
6
Transfer with V8
Transfer Procedure from the Editor to MONITOUCH
1. Connect MONITOUCH (USB-B) and the computer using a USB cable.
2. Click [Transfer] from the [File] menu or click the [Transfer] icon on the toolbar.
3. The [Transfer] dialog is displayed.
Select [Display] for [Transfer Device], and [Screen Data] for [Transfer Data].
Leave [ Use Simulator] unchecked at this time.
(When using Simulator, check this box.)
F 1
F 2
F 3
F 4
F 5
F 6
F 7
SYSTEM
USB-A USB-B
V8 series
Computer
USB cable
OR
