4.3 Drawing Methods
4-10
5. In the same manner, move the mouse to the second point and click.
6. At the end point, double-click the mouse button.
The continuous line is terminated.
7. To reset the drawing setting, right-click or double-click the mouse button.
By dragging the mouse again without resetting it, you can continuously draw another continuous
line.
Box
Rectangle
1. Click the “ ” mark on the right of the [Frame Type] icon on the toolbar.
Select the desired frame type from the list displayed. ([With Frame (Paint)] is selected as an
example.)
2. Likewise, select a line style from the [Line Type] icon and a frame color from the [Line Color/Frame
Color] icon respectively.
Start point First point
Click.
Second point
To erase the line you have drawn, right-click the mouse.
Start point
First point
Click.
Second point
Third point
Double-click.
End point
To Next Page
