5.16 Animation
5-75
5
Registration
Frame Editing
In the [Animation] window, double-click the desired [Frame No. xxxx] under an [Animation No. xxxx]
folder.
The [Frame Edit] window is displayed.
Frame Structure
A maximum of 1,023 frames from No. 0 to No. 1,022 can be registered.
The maximum capacity per frame is 1 MB.
The maximum permissible X and Y sizes of a pattern are 1,024 dots and 768 dots respectively.
Frame Editing
Frames can be edited in the same manner as for patterns.
Double-click on the frame
number.
For more information on editing, refer to page 5-40 .
To Next Page
