8.7 Other Functions in the [Tool] Menu
[Tool] Menu
The [Tool] menu provides the following functions:
*1 For more information on the Windows fonts, refer to “Windows Font” (page A1-29) described in
“Appendix 1 Font”.
*2 For more information on pasting screen image, refer to “Image File Import and Storage” (page
5-50) described in “5.10 Pattern”.
*3 For more information, refer to the manual “Connection to A • B Control Logix.”
Tool Uses Refer to:
Error Check Current editing files are checked for errors. page 8-64
List of Memory Use Memory capacity available on the current editing file is
displayed.
page 8-67
Memory Address Use Memory addresses used in the current editing file are
displayed.
page 8-53
Change Memory Memory addresses used in the current editing file are
changed.
page 8-69
Windows Font Change All The current setting for Windows fonts is changed at
one time.
*1
Windows Font List Windows font names used in the current editing file are
listed.
*1
Register Windows Font Windows fonts used for text and registered in the
current editing file are checked and changed.
*1
Paste Image File Image files (with extension of “bmp”, “jpg” or “jpeg”) are
imported as patterns.
*2
DXF File Convert DXF files are imported as graphics. page 8-73
Customize Contents of the toolbar are arranged as desired. page 8-57
Screen Image
(Save as Pattern Image)
The current screen image is registered as patterns. page 8-75
Screen Image
(Copy to Clipboard)
The current screen image is copied to the clipboard. page 8-38
Convert to Rich Text Format The printing image of a screen data is saved as a Rich
Text file format.
page 8-41
Tag Table Set the tag table when using Allen Bradley’s Control
Logix.
*3
