4.3 Drawing Methods
4-9
4
Drawing
Continuous Line
1. Click the “ ” mark on the right of the [Line Color/Frame Color] icon on the toolbar.
Select the desired color from the list displayed.
2. Click the “ ” mark on the right of the [Line Type] icon.
Select the desired line style from the list displayed.
3. Click the “ ” mark on the right of the [Line] icon on the toolbar.
The pull-down menu is displayed. Select [Continuous Line].
The [Continuous Line] icon is depressed and the mouse cursor is turned into a cross-shaped
cursor.
4. Click at the start point. Then click at the first point. The first line is drawn.
Start point First point
Click.
