4.3 Drawing Methods
4-15
4
Drawing
5. Drag from the end point of the upper side to the corresponding point of the lower side.
6. The parallelogram is drawn by clicking the mouse.
7. To reset the drawing setting, right-click or double-click the mouse.
By dragging the mouse again without resetting it, you can draw another parallelogram
continuously.
Polygon
1. Click the “ ” mark on the right of the [Frame Type] icon on the toolbar.
Select the desired frame type from the list displayed. ([With Frame (Paint)] is selected as an
example.)
2. Likewise, select a frame color from the [Line Color/Frame Color] icon and a color of the frame
inside from the [Paint Color] icon.
Drag.
To Next Page
