4.3 Drawing Methods
4-16
3. Click the “ ” mark on the right of the [Box] icon on the toolbar.
Click [Polygon] from the pull-down menu.
The [Polygon] icon is depressed and the mouse cursor is turned into a cross-shaped cursor.
4. Select the drawing method.
Click [View] → [Toolbar] → [Drawing Method].
The [Drawing Method] toolbar is displayed.
5. Click the “ ” mark on the right of the [Polygon] icon displayed at the extreme left of the toolbar.
The pull-down menu is displayed.
Selects [Polygon (Center)].
Polygon (Center):
Drag from the center
to a corner.
Polygon (Side):
Drag from the start point to
the end point of one side.
: Start point
: End point
To Next Page
