4.2 Attribute Setting Icon
4-7
4
Drawing
Selecting Arrow Type
The following arrowheads are available.
Selecting Line Style
Line styles can be selected for lines, boxes and circles.
There are six line styles available.
Limitations on Line Styles
• [Thick Line] can be selected for the following items.
straight lines, rectangles
• Line style selection is not possible for the following items. They are drawn with solid lines.
chamfered boxes (round chamfering, chamfering), parallelograms with frame (painted),
polygons, circles, sectors, ellipses
