Capacity for Parts Placement
The maximum number of parts permitted for one screen is determined, depending on the types of
parts. The limitation and the maximum number of the parts are listed below.
Parts Limit per ID
Limit per
Base/
Overlap
Limit per Screen
V815iX
V812(i)S
V810(i)T/S
V808(i)S
V810(i)C
V808(i)C
V808(i)CH
V806
Overlap Normal Overlap −−
3Call-overlap −−
Multi-overlap −−
Switch None None 1024 (*1) 192 (*1)
Lamp None None 1024 192
Data Display Numerical Data Display None None Setting memory
Character Display None None Setting memory
Message Display None None Setting memory
Table Data Display 1 256 Setting memory
Message Message 1 256 Setting memory
Comment Display 1 256 Setting memory
Entry 1 1 4
Slider Switch None None 1024 (*1) 192 (*1)
Graph Bar Graph None None Setting memory
Pie Graph None None Setting memory
Closed Area Graph None None Setting memory
Panel Meter None None Setting memory
Statistic Bar Graph 1 256 Setting memory
Statistic Pie Graph 1 256 Setting memory
Trend Trend Graph 1 256 Setting memory
Trend Sampling 1 256 Setting memory
Data Sampling 1 256 Setting memory
Alarm Alarm Tracking 1 256 Setting memory
Bit Order Alarming 1 256 Setting memory
Alarm Sub Display 1 256 Setting memory
Time Order Alarming 1 256 Setting memory
Alarm Logging 1 256 Setting memory
Graphic Graphic 1 256 Setting memory
Graphic Relay 1 256 Setting memory
Macro Macro 1 256 Setting memory
Interval Timer 1 256 Setting memory
Calendar Time Display None None Setting memory
Calendar 1 256 Setting memory
Recipe 1 4 Setting memory
