3.6 Parts
3-48
*1 Switches, slider switches, and scroll switches are included in these limits.
*2 These parts are not available with the 128-color type and the V806M model.
*3 A maximum of four memory card modes can be set on one screen (four layers) though there is a
limitation.
For instance, two layers of one screen cannot contain one list display each. But it is possible that
one part contains one list display, and a different part of the same screen contains one format
screen.
*4 When a screen library is placed on the screen, the parts registered in the screen library are
subject to the same limit of items in the chart above.
Setting memory
“Setting memory” in the previous chart means the number of memory locations, which is read on one
screen. This does not mean the number of words used on a screen.
The maximum permissible number of memory locations varies with models of the V8 series.
The read area under [System Setting] → [Device Connection Setting] → [Read/Write Area] is counted
as one memory location. (The write area is not the count target.) Therefore, to determine the
maximum number of memory locations for a part, subtract one from the number indicated in the above
chart.
Examples:
• One memory location is counted even when 10 words are used in bit order alarming.
• Switch output memory is not counted as setting memory. For lamp memory, however, each lamp
memory location used is counted as one.
• Each data display is counted as one memory location. If maximum and minimum values are set,
one memory location each is counted. Therefore, it is counted as three in total.
Multimedia Animation 1 256 Setting
memory
−−
Video 1 4 4 −−
JPEG Display 1 256 Setting memory
Sound 1 256 Setting
memory
−−
Network Camera Display 1 1 4 (*2)
Remote Desktop Display 1 1 4 (*2)
Others Data Block Area 1 4 4
Memory Card 1 1 4 (*3)
Memo Pad 1 1 1 (Not available with matrix type)
Screen Library None None (*4)
Parts Limit per ID
Limit per
Base/
Overlap
Limit per Screen
V815iX
V812(i)S
V810(i)T/S
V808(i)S
V810(i)C
V808(i)C
V808(i)CH
V806
Model No. of Memory Locations per Screen
V8 series 1024
V806 series 256
