2.5 Toolbar
2-23
2
Editor
Draw
1. Line Draws straight lines (or continuous lines).
2. Box Draws boxes (rectangles/parallelograms/polygons, etc.).
3. Circle Draws circles (ellipses/sectors/elliptical arcs, etc.).
4. Text Produces text (or multi-text).
5. Dot Draws dots.
6. Paint Paints.
7. Scale Draws scales (bar type/pie type/trend type).
8. Pattern/Library Places patterns (or graphic library/screen library).
9. Character Color Specifies a foreground color for text.
10. Line Color/Frame Color Specifies a line or frame color.
11. Paint Color/Background Specifies a background color for text or a paint color for boxes.
12. Arrow Type Specifies arrow type for straight lines.
13. Line Type Specifies line type such as straight lines, continuous lines or boxes.
14. Frame Type Specifies frame type for boxes or circles.
1. 2. 3. 4. 5. 6. 7. 8. 9. 10. 11. 12. 13. 14.
1.
5.
2. 3. 4.
7. 8.
12. 13. 14.
