2.3 Menu Item [View]

2-14

3. The item dialog is moved by dragging the title bar.

How to Inset

The list-view window in the “floating” status can be inset into the editing screen.

Double-click the title bar of the list-view window or drag it to a desired position. The window is inset

into the editing screen.

Drag the title bar. The dialog is moved.

Drag.
