6.1 Transfer Methods
6-4
Using a Modem
Screen data can be transferred via telephone line.
For more information, refer to page 6-49.
MJ1
PW ER OH CD DA
LINE
PW ER OH CD DA
LINE
F 1
F 2
F 3
F 4
F 5
F 6
F 7
SYSTEM
RS-232C cable included
with the modem
(straight)
Computer
(PC)
Telephone line modular socket
RS-232C cable (straight)
(V-CP + cross cable + RS-232C cable included with the modem)
Modular cable included
with the modem
Modular cable included
with the modem
Telephone line
modular socket
Telephone line modular socket
Modem
Modem
