4.3 Drawing Methods
4-23
4
Drawing
9. Clicking the mouse draws the arc or sector.
10. To reset the drawing setting, right-click or double-click the mouse.
By dragging the mouse again without resetting it, you can draw another arc or sector continuously.
Drawing method: [Arc and Sector (On Arc)]
1. Click the ā ā mark on the right of the [Frame Type] icon on the toolbar.
Select the desired frame type from the list displayed. ([With Frame (Paint)] is selected as an
example.)
2. Likewise, select a line style from the [Line Type] icon and a frame color from the [Line Color/Frame
Color] icon respectively.
3. Select a paint color for inside the frame from the [Paint Color] icon.
4. Click the [Arc] or [Sector] icon on the toolbar.
The icon is depressed and the mouse cursor is turned into a cross-shaped cursor.
To Next Page
