Siemens SCALANCE XR-500 Configuration Manual

Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
180 Configuration Manual, 11/2015, C79000-G8976-C252-10
Syntax
Call up the command with the following parameters:
map protocol
{ip | novell | netbios | appletalk | other <aa:aa>}
enet-v2 protocols-group <Group id integer(1-100)>
The parameters have the following meaning:
Parameter
Description
Range of values / note
ip
Internet Protocol v4
HEX 08:00
novell
Novell Netware protocol
HEX 81:38
netbios
Netbios via TCP/IP
HEX f0:f0
appletalk
Appletalk
HEX 80:9b
other
Other protocol. enter the hexadecimal protocol
value.
• other: aa:aa
• IPV6:
86:DD
• LLDP:
88:CC
• PTP IEEE1588:
88:F7
• EAP (802.1X):
88:8E
enet-v2
Frame structure is Ethernet II
-
protocols-group
Keyword for a protocol group
-
Group id integer
Number of the group
decimal 1 ... 100
Result
The protocol group is created.
Further notes
You delete the protocol group with the no map protocol command.
You can display the status of this function and other information with the
show vlan
protocols-group
command.
6.1.2.4
no map protocol
Description
With this command, you delete a protocol from all protocol groups.
Requirement
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
