Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
558 Configuration Manual, 11/2015, C79000-G8976-C252-10
Call up the command with the following parameters:
no vrrp <vrid(1-255)> associated-ip <ip_addr>
The parameters have the following meaning:
Value for an IPv4 address Enter a valid IPv4 address.
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
The IPv4 address is removed from the virtual router.
You configure a VRRP interface with the interface command.
You display the IPv4 addresses with the
show vrrp interface - vrid command.
vrrp group shutdown
Description
With this command, you remove all assigned IPv4 addresses from the virtual router.
Note
This command is available only with layer 3.
You are in the VRRP Interface configuration mode.
The command prompt is as follows:
cli(config-vrrp-if)#
