Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
796 Configuration Manual, 11/2015, C79000-G8976-C252-10
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Syntax
Call the command without parameter assignment:
show monitor barrier
Result
The settings are displayed.
12.4.1.3
show monitor session
Description
This command shows the settings used for mirroring ports.
You obtain information about the ports from which incoming and/or outgoing data traffic is
mirrored and the port at which the mirrored data is output.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Syntax
Call up the command with the following parameters:
show monitor {session <session-id(1-7)>}
The parameters have the following meaning:
Parameter
Description
Range of values / note
session
Keyword for a session whose settings
are displayed
-
session-id
Number of the session 1 ... 7
Result
The settings for mirroring ports are displayed.
