Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
561
Call up the command with the following parameters:
no vrrp <vrid(1-255)> preempt
The parameter has the following meaning:
The function is disabled.
You configure a VRRP interface with the interface command.
You assign IPv4 addresses to a virtual router with the
vrrp associated -ip command.
You enable the function with the
vrrp preempt command.
You can display the status of the function with the
show vrrp interface - vrid or with the
show vrrp interface command.
vrrp primary-ip
Description
With this command, you specify the primary IPv4 address specified with the VRRP packets
as the source address.
Note
This command is available only with layer 3.
You are in the VRRP Interface configuration mode.
The command prompt is as follows:
cli(config-vrrp-if)#
