Siemens SCALANCE XR-500

Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
800 Configuration Manual, 11/2015, C79000-G8976-C252-10
12.4.2.5
monitor session destination
Description
With this command, you configure the destination for mirroring a port.
Requirement
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
Syntax
Call up the command with the following parameters:
monitor session <session-id(1-7)> destination
{interface <interface-type><interface-id> | remote vlan <vlan-id (1-4094)>}
The parameters have the following meaning:
Parameter
Description
Range of values / note
session-id
Number of the session
7 parallel sessions are possible only with
port-based mirroring and their ports must
not overlap.
1 ... 7
interface
Keyword for a an interface description -
interface-type
Type or speed of the interface
Enter a valid interface.
If you connect a BUS ANALYZER Agent XM-400 with a
SCALANCE XM-400 basic device as of firmware version
5.1, you can select up to four ports of the BUS ANALYZER
Agent XM-400 as destination ports. The BUS ANALYZER
Agent XM-400 supports port-based and VLAN-based mirror-
ing.
interface-id
Module no. and port no. of the interface
remote vlan
Keyword for a RSPAN session
With RSPAN (Remote Switched Port
Analyzer) you can forward the data traffic
of a mirroring session to the monitor port
via a VLAN. On the RSPAN VLAN, the
mirrored data traffic is not disturbed by
other data.
-
vlan-id
Number of the VLAN for the RSPAN
session
1 ... 4094
