Layer 2 management protocols
8.6 Multicast
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
426 Configuration Manual, 11/2015, C79000-G8976-C252-10
Call up the command with the following parameters:
mac-address-table static multicast <aa:aa:aa:aa:aa:aa> vlan <vlan-id(1-4094)>
The parameters have the following meaning:
MAC address of the interface
Keyword for a VLAN connection -
Number of the addressed VLAN
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
If you do not select any parameters from the parameter list, the default value is used.
The settings for "static multicast" are configured.
You disable the setting with the no mac-address static multicast command.
no mac-address-table static multicast
Description
With this command, you delete a static multicast address.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
