Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
184 Configuration Manual, 11/2015, C79000-G8976-C252-10
The setting is disabled.
You enable the setting with the subnet-vlan command.
You can display the status of this function and other information with the
show vlan device
info
command.
With this command, you create a VLAN on the device and change to the VLAN configuration
mode.
In the provider backbone bridge mode, this command is used to create user, service and
backbone VLANs.
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
Call up the command with the following parameters:
vlan <vlan-id(1-4094)>
The parameter has the following meaning:
Number of the addressed VLAN
Do not enter any leading zeros with the number of the VLAN.
The VLAN is created.
You are now in the VLAN configuration mode.
The command prompt is as follows:
cli(config-vlan-$$$)#
