Siemens SCALANCE XR-500

Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
801
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
Note
Selecting the destination port
A port that is part of a port channel cannot
be configured as the destination port for a monitor
session.
Note
VLAN and ACL mirroring
Tx mirroring is not supported with VLAN or ACL mirroring.
Result
As soon as you have configured the settings for the port to be monitored and the destination
port, the session is complete and active.
Note
If you change the settings for an existing session, all previous configurations of this session
are lost.
Further notes
You delete the destination for mirroring a port with the no monitor session ... destination
command.
You end and delete a session with the
no monitor session command.
You display the configuration settings with the
show monitor session command.
12.4.2.6
no monitor session destination
Description
With this command, you delete the destination for mirroring a port.
Requirement
You are in the Global configuration mode.
The command prompt is as follows:
cli(config)#
