Siemens SCALANCE XR-500

Network structures
6.1 VLAN
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
192 Configuration Manual, 11/2015, C79000-G8976-C252-10
Syntax
Call up the command with the following parameters:
switchport map protocols-group
<group id(0-2147483647)>vlan<vlan-id(1-4094)>
The parameters have the following meaning:
Parameter
Description
Range of values / note
group id
Number of the group
0 ... 2147483647
vlan Keyword for a VLAN connection -
vlan-id
Number of the addressed VLAN
1 ... 4094
Result
The group is assigned to the port and the VLAN.
Further notes
You delete the setting with the no switchport map protocols-group command.
You can display the status of this function and other information with the
show vlan
protocols-group
command.
6.1.3.8
no switchport map protocols-group
Description
With this command, you delete the assignment of a configured protocol group to a specific
VLAN.
Requirement
You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
Syntax
Call up the command with the following parameters:
no switchport map protocols-group <group id(0-2147483647)>
The parameter has the following meaning:
Parameter
Description
Range of values / note
group id
Number of the group 0 ... 2147483647
Result
The assignment is deleted.
