Siemens SCALANCE XR-500 Configuration Manual

Layer 3 functions
9.8 Route maps (IPv4 / IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
628 Configuration Manual, 11/2015, C79000-G8976-C252-10
Requirement
You are now in the Route maps configuration mode.
The command prompt is as follows:
cli(config-rmap-$$$)#
Syntax
Call up the command with the following parameters:
match destination ip <Ip address> <Net Mask>
The parameters have the following meaning:
Parameter
Description
Range of values / note
Ip address
IPv4 address Enter the IPv4 address of the destination on which the filter-
ing is based.
Net Mask
Subnet mask of the corresponding
subnet
Enter the subnet mask of the destination on which the filter-
ing is based.
Result
The filter for the destination IPv4 address is created.
Further notes
You delete the filter for the destination IPv4 address with the no match destination ip
command.
You create a filter for the destination IPv6 address with the
match destination ipv6
command.
You change to the Route maps configuration mode with the command
route-map.
You display the setting and other information with the
show route-map command.
9.8.3.2
no match destination ip
Description
With this command, you delete the filter for the destination IPv4 address.
Note
This command is available only with layer 3 (IPv4).
Requirement
You are now in the Route maps configuration mode.
The command prompt is as follows:
cli(config-rmap-$$$)#
