Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
567
The authentication is disabled.
You configure a VRRP interface with the interface command.
You enable the authentication with the
vrrp text-authentication command.
You assign IPv4 addresses to a virtual router with the
vrrp associated-ip command.
With this command, you specify the time interval after which a virtual router with the "Master"
status sends an advertisement packet again.
Note
This command is available only with layer 3.
● An IPv4 address is assigned to the virtual router.
● You are in the VRRP Interface configuration mode
.The command prompt is:
cli(config-vrrp-if)#
Call up the command with the following parameters:
vrrp <vrid(1-255)> timer <interval(1-255)secs>
The parameters have the following meaning:
Time interval in seconds 1 ... 255
The time interval is specified
