Siemens SCALANCE XR-500 Configuration Manual

Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
471
Further notes
You enable the function with the default-information originate always command.
9.2.3.17
network area
Description
With this command, you specify an OSPF interface and the Area ID connected to the OSPF
interface.
Note
This command is available only with layer 3.
Requirement
You are in the OSPF Router configuration mode.
The command prompt is as follows:
cli(config-ospf)#
Syntax
Call up the command with the following parameters:
network <network number> area <area-id>
The parameters have the following meaning:
Parameter
Description
Range of values / note
network number
IP interface that will be used by OSPF. Enter the IP address of the inter-
face for which OSPF will be ena-
bled.
area-id
Area-ID specify an ID.
x.x.x.x
x = 0 ... 255
0.0.0.0 = backbone area
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
Result
The OSPF interface is configured.
Further notes
You remove the OSPF interface and the area with the no network area command.
You can display the status of this function and other information with the
show ip ospf
interface
command.
