Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
563
Call up the command with the following parameters:
no vrrp <vrid(1-255)> ipv4 <ucast_addr > [secondary]}]
The parameters have the following meaning:
Value for an IPv4 unicast address Enter a valid IPv4 unicast ad-
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
The IPv4 address is removed from the virtual router.
You configure a VRRP interface with the interface command.
You assign IPv4 addresses to a virtual router with the
vrrp associated-ip command.
You display the IPv4 addresses with the
show vrrp interface - vrid command.
vrrp priority
Description
With this command, you specify the priority of the virtual router. The current master router is
automatically given 255. All other priorities can be distributed freely among the VRRP
routers. The higher the priority, the earlier the VRRP router becomes "Master".
Note
This command is available only with layer 3.
● An IPv4 address is assigned to the virtual router.
● You are in the VRRP Interface configuration mode
.The command prompt is:
cli(config-vrrp-if)#
