Layer 3 functions
9.3 OSPFv3 (IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
519
You delete the address range with the no area range command.
You configure the area with the
area command.
You can display the status of this function and other information with the
show ipv6 ospf -
area-range / summary-address
command.
area virtual-link
Description
With this command you configure a virtual point-to-point link from a backbone router to a
router of a remote area. The transit areas are the areas that are bridged.
Note
This command is available only with layer 3.
● The router is an Area Border Router (ABR) or an Autonomous System Boundary Router
(ASBR).
● No stub area
● The virtual link needs to be configured on both routers
● Both routers are connected to the transit area.
● You are in the OSPFv3 router configuration mode.
The command prompt is as follows:
cli(config-ospfv3)#
