Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
216 Configuration Manual, 11/2015, C79000-G8976-C252-10
Syntax
Call up the command with the following parameters:
show spanning-tree interface <interface-type><interface-id>
[{cost|priority|portfast|rootcost|restricted-role|
restricted-tcn|state|stats|detail}]
The parameters have the following meaning:
Parameter
Description
Range of values / note
interface-type
Type or speed of the interface
Enter a valid interface.
interface-id
Module no. and port no. of the interface
cost
Shows the port costs used to calculate
the lowest-cost path.
-
priority
Shows the priority of the port. -
portfast
Shows whether spanning-tree port-
fast is enabled.
-
rootcost
Shows the costs of the path to the root
bridge.
-
restricted-role
Shows whether spanning-tree re-
stricted-role is enabled.
-
restricted-tcn
Shows whether spanning-tree re-
stricted-tcn is enabled.
-
state
Shows the status of the interface.
-
stats
Shows the counters of the various
BPDU transmissions.
-
detail
Shows detailed information about the
spanning tree settings of the interface.
-
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
Result
The settings of the ports for the spanning tree function are displayed.
6.3.1.7
show spanning-tree interface layer2-gateway-port
Description
This command shows the settings of Layer 2 Gateway Port (L2GP). For example the priority,
the MAC address and the status of L2GP are displayed.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
