Layer 3 functions
9.6 RIPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
591
Syntax
Call up the command with the following parameters:
no vrrp <vrid(1-255)> timer <interval(50-4095)centiseconds>
The parameters have the following meaning:
Parameter
Description
Range of values / note
vrid
ID of the virtual router
1 ... 255
interval
Time interval in hundredths of seconds 50 ... 4095
Result
The time interval is reset.
Further notes
You configure a VRRP3 interface with the interface command.
You enable routing with VRRP3 with the
router vrrp3 command.
You configure the interval with the
vrrp timer command.
You assign IP addresses to a virtual router with the
vrrp associated -ip command.
You show the interval with the
show vrrp3 interface - vrid command.
9.6
RIPv2 (IPv4)
This section describes the commands relevant for working with routing with RIPv2.
RIPv2 is only used with IPv4 and is defined in RFC 2453. It is based on the distance vector
algorithm of Bellman-Ford.
RIPv2 uses the UDP port 520.
9.6.1
show ip rip
Description
This command shows the RIP information.
Requirement
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
