Layer 3 functions
9.4 VRRPv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
566 Configuration Manual, 11/2015, C79000-G8976-C252-10
The parameters have the following meaning:
Password Enter a password. Maximum
The authentication is enabled.
You configure a VRRP interface with the interface command.
You disable the authentication with the
no vrrp text-authentication command.
You assign IPv4 addresses to a virtual router with the
vrrp associated-ip command.
no vrrp text-authentication
Description
Was this command, you specify that VRRP packets are not authenticated.
Note
This command is available only with layer 3.
● An IPv4 address is assigned to the virtual router.
● You are in the VRRP Interface configuration mode
.The command prompt is:
cli(config-vrrp-if)#
Call up the command with the following parameters:
no vrrp <vrid(1-255)> text-authentication
The parameter has the following meaning:
