Network structures
6.3 Spanning Tree
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
213
Call up the command with one of the following parameter assignments:
show spanning-tree mst[<instance-id(1-64)>][detail]
The parameters have the following meaning:
Number of the instance or range of
instances whose settings are displayed
1 ... 64
Shows detailed information about the
selected interface
-
The settings for the spanning tree configuration are displayed.
You display the general settings for the Spanning Tree Protocol with the show spanning-tree
command.
show spanning-tree active
Description
This command shows the settings for the active ports of the spanning tree function.
You are in the User EXEC mode or in the Privileged EXEC mode.
The command prompt is as follows:
cli> or cli#
Call up the command with the following parameters:
show spanning-tree active [detail]
The parameter has the following meaning:
