Diagnostics
12.2 FMP
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
784 Configuration Manual, 11/2015, C79000-G8976-C252-10
With this command, you specify the limit values for monitoring the received power per port.
You are in the Interface configuration mode.
The command prompt is:
cli(config-if-$$$)#
Call up the command with the following parameters:
rmon rx-power [req]<1/10 dBm> [dem]<1/10 dBm>
The parameters have the following meaning:
Specify the value at which you are informed of
the deterioration of the received power by a
message of the severity level "Warning"
0 ... -40 dB
The default value depends on the rele-
vant pluggable transceiver.
Specify the value at which you are informed of
the deterioration of the received power by a
message of the severity level "Critical"
0 ... -40 dB
The default value depends on the rele-
vant pluggable transceiver.
The limits for monitoring the received power are defined.
You enable this function with the fmp command.
You disable this function with the
no fmp command.
You display the status of this function and other information with the
show fmp stauts and
show fmp limit commands.
You define the limit values for the power loss with the command
fmp power-loss.
