Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
482 Configuration Manual, 11/2015, C79000-G8976-C252-10
The address range is deleted.
You configure the address range with the summary-address command.
Commands in the Interface Configuration mode
This section describes commands that you can call up in the interface configuration mode.
Depending on the Interface selected, various command sets are available.
In the Global configuration mode, enter the
interface command to change to this mode.
Commands relating to other topics that can be called in the interface configuration mode can
be found in the relevant sections.
● If you exit the Interface configuration mode with the
exit command, you return to the
Global configuration mode.
● If you exit the Interface configuration mode with the
end command, you return to the
Privileged EXEC mode.
ip ospf authentication
Description
With this command, you specify the type of authentication. The following methods are
possible:
● Authentication using an unencrypted password.
● Authentication using MD5
vailable only with layer 3.
● The interface is an IP interface.
● Authentication using MD5: A password and a key ID are created.
● Authentication using an unencrypted password: A password is created.
● You are in the Interface configuration mode.
The command prompt is as follows:
cli(config-if-$$$)#
