Siemens SCALANCE XR-500 Configuration Manual

Layer 3 functions
9.3 OSPFv3 (IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
520 Configuration Manual, 11/2015, C79000-G8976-C252-10
Syntax
Call up the command with the following parameters:
area <area-id> virtual-link <router-id>
[hello-interval <seconds>]
[retransmit-interval<seconds>]
[transmit-delay <seconds>]
[dead-interval<seconds>]
The parameters have the following meaning:
Parameter
Description
Range of values / note
area-id
Area ID Specify the ID in the IPv4 address format
x.x.x.xx = 0 ... 255
0.0.0.0 = backbone area
router-id
Router ID of the virtual router in the transit area Specify the ID in the IPv4 address format
x.x.x.xx = 0 ... 255
hello-interval
Keyword for the interval at which Hello packets
are sent over the virtual link
-
seconds
Length of the interval 1 ... 65535 s
Default: 10
The routers located on the same link
must have the same interval.
retransmit-interval
Keyword for the interval after which packets
whose receipt was not confirmed are trans-
ferred again.
-
seconds
Length of the interval 0 ... 3600 s
Default: 20
transmit-delay
Keyword for the time that a link state update
packet requires for transmission over the virtual
link.
--
seconds
Length of the interval 0 ... 3600 s
Default: 1
dead-interval
Keyword for the interval after which the neigh-
bor router is classified as "failed" if Hello pack-
ets from it are not received.
-
seconds
Length of the interval 1 ... 65535 s
Default: 60
The value must be a multiple of the hello
interval.
The routers located on the same link
must have the same interval.
Result
The virtual link is created.
