Introduction
1.1 Information on the configuration manual (CLI)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
28 Configuration Manual, 11/2015, C79000-G8976-C252-10
Orientation in the documentation
Apart from this configuration manual, the products also have the following documentation:
● Configuration Manual:
– SCALANCE XM-400/XR-500 Web Based Mangement
This document is intended to provide you with the information you require to commission
and configure IE switches using Web Based Management.
● Operating instructions:
– SCALANCE XR-500
– MM900 media modules for SCALANCE XR-500M
– Fan unit FAN597-1 for SCALANCE XR-500M
– Power supply PS598-1 for SCALANCE XR-500M
– SCALANCE XM-400
– Extender for SCALANCE XM-400
– Pluggable transceiver SFP/SFP+/SCP/STP
– PoE power supply SCALANCE PS9230 PoE/SCALANCE PS924 PoE
These documents contain information on installing and connecting up and approvals for
the products.
The following documentation is also available from SIMATIC NET on the topic of Industrial
Ethernet:
● System manual "Industrial Ethernet / PROFINET"
● System manual "Industrial Ethernet / PROFINET - Passive network components"
Note
All these documents are available on the SCA
LANCE X DVD.
Terms used
The designation . . .
stands for . . .
IE switch
Industrial Ethernet switch
IPv4 address
IPv4 address
IPv6 address
IPv6 address
IP address
IPv4 / IPv6 address
IPv4 interface
Interface that supports IPv4.
IPv6 interface Interface that supports IPv6. The interface can have more
than one IPv6 address The IPv6 addresses have different
ranges (scope), e.g. link local
IP interface Interface that supports both IPv4 and IPv6. As default the
IPv4 support is already activated. The IPv6 support needs to
be activated extra.
