Description
2.6 Interface identifiers and addresses
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
40 Configuration Manual, 11/2015, C79000-G8976-C252-10
Available physical interfaces
Available interface types
SCALANCE XM-400 and SCALANCE XR-500 support the following interface types:
Note
If you use an MM900 media module with an optical interface, use
gigabitethernet for the
-type parameter. For further information on the media modules, refer to the
compact operating instructions of the MM900 media modules for SCALANCE X
R-500.
Available interface identifiers with SCALANCE XM-400
● Interfaces of the basic device
The interfaces of the basic device SCALANCE XM-400 are called module 1.
● Interfaces of extenders
The port extenders are called module 2 and module 3 starting from the basic device. The
number of port extenders depends on the number of ports of the basic device.
Function extenders are module 0.
Available interface identifiers with SCALANCE XR-500
● Fixed interfaces
The interfaces permanently installed in the SCALANCE XR-500 are identified with
module 0.
cpu0: Out of band interface
● Interfaces of modules
The slots for modules are called module 1 and the following numbers. The numbering
range depends on the hardware configuration. The numbering is fixed and does not
depend on the number of modules being used.
Each module has 4 ports numbered 1 to 4.
