Siemens SCALANCE XR-500 Configuration Manual

Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
443
Syntax
Call up the command with the following parameters:
show ip ospf
[area-id]
database
{
asbr-summary|external|network|
nssa-external|router|summary
}
[link-state-id]
[{
adv-router <ip-address>|self-originate
}]
The parameters have the following meaning:
Parameter
Description
Range of values / note
area-id
Area-ID specify an ID.
x.x.x.x
x = 0 ... 255
0.0.0.0 = backbone area.
asbr-summary
only shows information of the LSA type
ASPR (Autonomous System Border
Router). (Type 4)
-
external
only shows information of the LSA type
"External" (Type 5)
-
network
only shows information of the LSA type
"Network" (Type 2)
-
nssa-external
only shows information of the LSA type
"NSSA (Not so stubby area) External"
(Type 7)
-
router
only shows information of the LSA type
"Router" (Type 1)
-
summary
only shows information of the LSA type
"Summary" (Type 3)
-
link-state-id
ID of the LSA .
Link State ID depends on the LSA
type.
Link State ID consists of 4 num-
bers each between 0 and 255
adv-router
Keyword for the router-specific LSA
-
ip-address
shows the router-specific LSA for a
specific IP address
specify a valid IP address.
If no IP address is entered, the
specific LSAs of the local router
are displayed.
self-originate
Num
ber of LSAs generated by the local
router
-
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
