Siemens SCALANCE XR-500 Configuration Manual

Layer 3 functions
9.2 OSPFv2 (IPv4)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
462 Configuration Manual, 11/2015, C79000-G8976-C252-10
The parameters have the following meaning:
Parameter
Description
Range of values / note
area-id
Area-ID specify a valid ID.
x.x.x.x
x = 0 ... 255
0.0.0.0 = backbone area
router-id
ID of the router. The router ID must
correspond to the IP address of the
interface of the transit area network.
-
authentication
Keyword for the authentication method
of the virtual connection
•
simple
enables authentication using a
password
•
messagedigest
enables authentication using
MD5
•
none
no authentication
hello-interval
Keyword for the interval at which Hello
packets are sent over the virtual link
-
value
specifies the length of the interval in
seconds.
enter the interval
1-65535
retransmit-interval
Keyword for the interval after which
packets whose receipt was not con-
firmed are transferred again.
-
value
specifies the length of the interval in
seconds.
enter the interval
0-3600
transmit-delay
Keyword for the time that a link state
update packet requires for transmis-
sion over the virtual link.
-
value
Specifies the length of the interval in
seconds.
enter the interval
0-3600
dead-interval
Keyword for the interval after which the
neighbor router is classified as "failed"
if Hello packets from it are not re-
ceived.
-
value
Specifies the length of the interval in
seconds.
enter the interval
0–0x7fffffff
authentication-key
Keyword for the unencrypted password
-
key
Password enter the password.
Maximum length: 8 characters
message-digest-key
Keyword for the ID of the password
-
key-id
ID of the password. specify the ID
0 ... 255
md5
Keyword for the password
-
key
Password enter the password
Maximum length: 16 characters
