Layer 3 functions
9.3 OSPFv3 (IPv6)
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
515
Call up the command with the following parameters:
area <Area-ID> range
<IPv6-Prefix> <Prefix-Length>
[{
advertise | not-advertise
}]
{
summary | Type7
}
[tag <tag-value>]
The parameters have the following meaning:
Area ID Specify the ID in the IPv4 address
format
x.x.x.x = 0 ... 255
Enter a valid IPv6 address
Number of bits belonging to the prefix
1 ... 128 bits
128: The node (host) itself
The address range is advertised outside the ranges.
If the Area ID is 0.0.0.0, the router generates an LSA
message of Type 3.
If the Area ID is not 0.0.0.0, the router generates an LSA
message of type 7 in an NSSA.
-
The address range is not advertised to the outside.
LSA type 3: Inter-area prefix LSA
Value that is assigned to the aggregated routes.
1 ... 65535
For information on identifiers of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
The address range is configured.
You delete the address range with the no area range command.
You configure the area with the
area command.
You can display the status of this function and other information with the
show ipv6 ospf -
area-range / summary-address
command.
