Diagnostics
12.4 Port Mirroring
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
803
● Monitoring is enabled.
● You are in the Global configuration mode
.The command prompt is:
cli(config)#
Call up the command for the port to be monitored with the following parameter assignment:
monitor session<session-id(1-7)> source
{interface {<interface-type><interface-id> | port-channel <port-channel-id (1-8)>}
[{rx|tx|both}]}
or
Call up the command for the VLAN to be monitored with the following parameter assignment:
monitor session <session-id (1-1)> source
{vlan <vlan-id> | mac-acl <acl-id>} | ip-acl <acl-id>}
The parameters have the following meaning:
Number of the session
7 parallel sessions are possible only
with port-based mirroring and their
1 ... 7
Keyword for a an interface description
Type or speed of the interface
Enter a valid interface.
Module no. and port no. of the interface
Keyword for a port channel connection
Number of the addressed port channel
Received data traffic will be mirrored
-
Transmitted data traffic will be mirrored
-
Received and sent data traffic will be
-
Keyword for a VLAN connection
Keyword for a MAC access control list
Keyword for an IP access control list
Number of the Access Control List
For information on names of addresses and interfaces, refer to the section "Interface
identifiers and addresses (Page 39)".
