3.6 Parts
3-59
3
Screen Editing
Files used for parts modification (for the V8, V7, V6, or V4 series)
Parts such as switches, lamps, or data displays (“SP” or “MP” parts mentioned on page 3-45) are
registered in screen data files or parts files.
When replacing a placed part with another one, select the necessary file and select your desired part
from it.
There are the following parts files with six different extensions:
The following parts files are provided from Hakko Electronics.
• Screen data file (e.g. V7 series)
File Extension Type
Screen data file
*.V7 V8/V7 series
*.V6 V6 series
*.V4 V4 series
Parts file
*.V7P V8/V7 series
*.V6P V6 series
*.V4P V4 series
Parts Screen Data File Name
Overlap Parts_Ovlp.V7
Switch Parts_Sw.V7
Lamp Parts_Lp.V7
Numerical Data Display Parts_NumDsp.V7
Character Display Parts_CharDsp.V7
Message Display Parts_MsgDsp.V7
Table Data Display Parts_GridDsp.V7
Bit Order Alarming Parts_Relay.V7
Alarm Sub Display Parts_RelaySub.V7
Message Parts_MassageMode.V7
Entry Parts_EntryMode.V7
Data Block Area Parts_DataBlockArea.V7
Keypad Parts_KeypadGp.V7
Bar Graph Parts_BarGraph.V7
Pie Graph Parts_PieGraph.V7
Panel Meter Parts_PanelMeter.V7
Statistic Bar Graph Parts_Stat_BarGraph.V7
Statistic Pie Graph Parts_Stat_PieGraph.V7
Trend Graph Parts_TrendGraph.V7
Closed Area Graph Parts_ClosedAreaGraph.V7
Graphic Parts_GraphicMode.V7
Graphic Relay Parts_GraphicRelay.V7
Trend Sampling Parts_TrendSampling.V7
Data Sampling Parts_Datasampling.V7
Alarm Logging Parts_BitSampling.V7
Time Order Alarming Parts_RelaySampling.V7
Alarm Tracking Parts_AlarmDsp.V7
Time Display Parts_DateDsp.V7
