4.3 Drawing Methods
4-27
4
Drawing
3. Click the [Elliptical Arc] or [Elliptical Arc] icon on the toolbar.
The icon is depressed and the mouse cursor is turned into a cross-shaped cursor.
4. Select the drawing method.
Click [View] → [Toolbar] → [Drawing Method].
The [Drawing Method] toolbar is displayed.
5. Click the “ ” mark on the right of the [Elliptical Arc/Elliptical Sector] icon.
The pull-down menu is displayed.
Select [Elliptical Arc (Center)].
To Next Page
