5.6 Graphic Library
5-21
5
Registration
3. Pattern
• Start point
The top left corner of the pattern becomes the start point.
• (Pattern) No.
When a parameter for pattern number has been set, commanding the pattern number brings
up the corresponding graphic.
4. Paint (start point)
The start point coordinates can be changed by a command from memory specified with a
parameter.
In this case, only REP is available; therefore, the previous paint (e.g.: circle) remains.
Parameter No. 1
Parameter No. 2
Wine
Beer Soda Water
Vodka
No. 0 No. 1 No. 2 No. 3
No. 4
Wine
No. 0
Soda
No. 2
Water
No. 3
PatternPattern
