Hakko Electronics V8 series - Page 392

6.5 Transfer Procedure (Using a Card)
6-44
2) Click [Transfer] from the [File] menu or click the [Transfer] icon on the toolbar.
3) The [Transfer] dialog is displayed.
Select [Card Recorder] for [Transfer Device], and [Screen Data] for [Transfer Data].
(To transfer all data, check [ All data transfer]. In this example, the screen data is transferred
alone.)
4) Click the [Communication Setting] button.
The [Communication Setting] dialog is displayed.
OR
