Siemens SCALANCE XR-500 Configuration Manual

Description
2.3 Configuration limits
SCALANCE XM-400/XR-500 Command Line Interface (CLI)
Configuration Manual, 11/2015, C79000-G8976-C252-10
35
Configurable function
Maximum number
Static MAC addresses in the Forward Database (FDB)
256
Multicast addresses without active GMRP 512
Multicast addresses with active GMRP
50
VLANs whose data traffic can be mirrored to a monitor port 255
RSPAN sessions
1
Layer 3
IP interfaces
127
Entries in the hardware routing table
4096
Static routes
100
Possible routes to the same destination
8
DHCP Relay Agent interfaces
127
DHCP Relay Agent servers
4
VRRP router interfaces (only VLAN interfaces)
52
OSPF areas per device
5
OSPFv2 area range entries per OSPF area (intra-area sum-
mary)
3
OSPFv3 area range entries per OSPF area (intra-area sum-
mary)
10
OSPF interfaces
40
OSPF interfaces per OSPF area
40
OSPF virtual links (within an autonomous system)
8
OSPFv3 neighbors
300
OSPFv3 neighbors per interface
8
OSPFv3 routes 1500
OSPFv2 interfaces authentication keysl 200
(40 interfaces each with 5
keys)
OSPFv2 virtual links authentication keys 40
(8 virtual links each with
5 keys)
Security
IP addresses from RADIUS servers
3
Management ACLs (access rules for management)
10
Rules for port ACL MAC
128
Ingress and egress rules for port ACL MAC (total)
364
Rules for port ACL IP
128
Ingress and egress rules for port ACL IP (total)
364
Rules for VLAN ACL IP
128
