Send documentation comments to mdsfeedback-doc@cisco.com
22-217
Cisco MDS 9000 Family Command Reference
OL-16217-01, Cisco MDS SAN-OS Release 3.x
Chapter 22 Show Commands
show ivr
The following example displays the combined user-defined and the automatically discovered IVR VSAN
topology database.
switch(config)# show ivr vsan-topology
AFID SWITCH WWN Active Cfg. VSANS
--------------------------------------------------------------
1 20:00:00:0d:ec:04:99:00 yes no 1-4
1 20:00:00:0d:ec:0e:9c:80 * yes no 2,6-7,9
1 20:00:00:0d:ec:0e:b0:40 yes no 1-3,5,8
1 20:00:00:0d:ec:04:99:00 no yes 1-4
1 20:00:00:0d:ec:0e:9c:80 * no yes 2,6-7,9
1 20:00:00:0d:ec:0e:b0:40 no yes 1-3,5,8
Total: 6 entries in active and configured IVR VSAN-Topology
Table 22-6 describes the significant fields shown in the show ivr vsan-topology display.
The following example displays the IVZ configuration.
switch# show ivr zone
zone name Ivz_vsan2-3
pwwn 21:00:00:e0:8b:02:ca:4a vsan 3
pwwn 21:00:00:20:37:c8:5c:6b vsan 2
zone name ivr_qa_z_all
pwwn 21:00:00:e0:8b:06:d9:1d vsan 1
pwwn 21:01:00:e0:8b:2e:80:93 vsan 4
pwwn 10:00:00:00:c9:2d:5a:dd vsan 1
pwwn 10:00:00:00:c9:2d:5a:de vsan 2
pwwn 21:00:00:20:37:5b:ce:af vsan 6
pwwn 21:00:00:20:37:39:6b:dd vsan 6
pwwn 22:00:00:20:37:39:6b:dd vsan 3
pwwn 22:00:00:20:37:5b:ce:af vsan 3
pwwn 50:06:04:82:bc:01:c3:84 vsan 5
The following example displays the active IVZS configuration.
switch# show ivr zoneset active
zoneset name IVR_ZoneSet1
zone name Ivz_vsan2-3
pwwn 21:00:00:e0:8b:02:ca:4a vsan 3
pwwn 21:00:00:20:37:c8:5c:6b vsan 2
The following example displays information for a specified IVZ.
switch# show ivr zone name Ivz_vsan2-3
zone name Ivz_vsan2-3
pwwn 21:00:00:e0:8b:02:ca:4a vsan 3
pwwn 21:00:00:20:37:c8:5c:6b vsan 2
Ta b l e 22-6 show ivr vsan-topology Field Descriptions
Field Description
AFID Autonomous fabric ID (AFID)
Switch WWN Switch world wide number
Active Automatically discovered
Cfg. Manually configured
VSANS VSANs configured
