Send documentation comments to mdsfeedback-doc@cisco.com
22-262
Cisco MDS 9000 Family Command Reference
OL-16217-01, Cisco MDS SAN-OS Release 3.x
Chapter 22 Show Commands
show nasb
NASB: module 8 vsan 3:DPP-6, VT-nWWN=250a000530002926, pWWN=250b000530002926 (not
provisioned)
NASB: module 8 vsan 3:DPP-7, VT-nWWN=250c000530002926, pWWN=250d000530002926 (not
provisioned)
NASB: module 8 vsan 3:DPP-8, VT-nWWN=250e000530002926, pWWN=250f000530002926 (not
provisioned)
The following example displays the NASB configuration on the SSM in slot 4.
switch# show nasb module 4
NASB: module 4 vsan 1:DPP-1, VT-nWWN=2700000530002926, pWWN=2701000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-2, VT-nWWN=2702000530002926, pWWN=2703000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-3, VT-nWWN=2704000530002926, pWWN=2705000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-4, VT-nWWN=2706000530002926, pWWN=2707000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-5, VT-nWWN=2708000530002926, pWWN=2709000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-6, VT-nWWN=270a000530002926, pWWN=270b000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-7, VT-nWWN=270c000530002926, pWWN=270d000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-8, VT-nWWN=270e000530002926, pWWN=270f000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-1, VT-nWWN=26f0000530002926, pWWN=26f1000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-2, VT-nWWN=26f2000530002926, pWWN=26f3000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-3, VT-nWWN=26f4000530002926, pWWN=26f5000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-4, VT-nWWN=26f6000530002926, pWWN=26f7000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-5, VT-nWWN=26f8000530002926, pWWN=26f9000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-6, VT-nWWN=26fa000530002926, pWWN=26fb000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-7, VT-nWWN=26fc000530002926, pWWN=26fd000530002926 (provisioned)
NASB: module 4 vsan 3:DPP-8, VT-nWWN=26fe000530002926, pWWN=26ff000530002926 (provisioned)
The following example displays the NASB configuration on the SSM in slot 4 and VSAN 1.
switch# show nasb module 4 vsan 1
NASB: module 4 vsan 1:DPP-1, VT-nWWN=2700000530002926, pWWN=2701000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-2, VT-nWWN=2702000530002926, pWWN=2703000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-3, VT-nWWN=2704000530002926, pWWN=2705000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-4, VT-nWWN=2706000530002926, pWWN=2707000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-5, VT-nWWN=2708000530002926, pWWN=2709000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-6, VT-nWWN=270a000530002926, pWWN=270b000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-7, VT-nWWN=270c000530002926, pWWN=270d000530002926 (provisioned)
NASB: module 4 vsan 1:DPP-8, VT-nWWN=270e000530002926, pWWN=270f000530002926 (provisioned)
Table 22-7 describes the significant fields shown in the display.
Ta b l e 22-7 show nasb Field Descriptions
Field Description
tpc module Displays the slot number of the SSM.
vsan Displays the VSAN number in the database associated to the NASB
process.
DPP- Displays which of the eight data path processors (DPP) is forwarding the
data.
VT-nWWN= Displays the virtual target (VT) node WWN associated with this XCopy
LUN.
pWWN= Displays the port WWN associated with this XCopy LUN.
provisioned Implies the range of FC slot/port-port interfaces has been enabled using
the ssm enable feature nasb command.
not provisioned Implies the range of FC slot/port-port interfaces has not been enabled
using the ssm enable feature nasb command.
