show zone analysis
The following example displays detailed statistics and analysis of the full zoning database.
switch# sh zone analysis vsan 1
Zoning database analysis vsan 1
Full zoning database
Last updated at: 14:36:56 UTC Oct 04 2005
Last updated by: Local [CLI / SNMP / GS / CIM / INTERNAL] or
Merge [interface] or
Remote [Domain, IP-Address]
[Switch name]
Num zonesets: 1
Number of devices zoned in
vsan: a/b (Unzoned: c |
Default-zone: d)
Displays the number of devices that are present in the zoning
configuration.
• a = The number of unique resolved members in the active
database.
• b = The number of devices logged in, which is the same as the
number of entries in the Fibre Channel name server (FCNS)
database.
• c = The number of devices logged in, but not zoned in the
zoning configuration.
• d = The number of devices in the default zone. d is displayed
only if the default zoning policy is permit.
Number of zone members
resolved: a/b (Unresolved: c)
Displays the number of members that are resolved in this VSAN in
the form: a out of b members in the zone set are resolved.
The number of resolved members is not necessarily unique. For
example, if a pWWN member and a fWWN member resolve to the
same FC ID, then that member is counted as two resolved members
out of two members present.
• a = The number of members resolved.
• b = The total number of members present.
• c = The total number of members unresolved.
Num zones Displays the total number of zones that are present in the active zone
set.
Number of IVR zones Displays the number of zones added and activated by IVR.
Number of IPS zones Displays the number of zones added and activated by the IP Storage
services manager (IPS-MGR).
Formatted database size Displays the total size of the active database when formatted to be
sent over the wire.
The formatted database size is displayed in kilobytes (KB) in this
format:
< X KB / Y KB, as in the following example.
Formatted database size: < 1 KB/2000 KB
In this example, the formatted database size is less than 1 KB out of
the maximum size of 2000 KB.
Table 22-13 show zone analysis Field Descriptions for the Active Zoning Database
Field Description
