Chapter 1 CLI Overview
Navigating Through CLI Commands
The Cisco Fabric Switch for IBM BladeCenter has a different port naming convention from the Cisco
MDS 9000 Family. There are six external ports and they are labeled ext0 and ext15 through ext19. There
are 14 internal ports and they are labeled bay1 through bay14.
Table 1-6 shows the port mapping between
the Cisco MDS 9000 Family switches and the Cisco Fabric Switch for IBM BladeCenter switches.
fc1/14 ext2
fc1/15 bay2
fc1/16 bay1
fc1/17 bay10 PortGroup 5
fc1/18 ext3
fc1/19 bay9
fc1/20 ext 4
fc1/21 bay16 PortGroup 6
fc1/22 bay8
fc1/23 ext6
fc1/24 ext5
Table 1-5 Port Mapping Between the Cisco MDS 9000 Family and the Cisco Fabric Switch for HP
c-Class BladeSystem
Cisco MDS 9000 Family Port
Cisco Fabric Switch for HP
c-Class BladeSystem Port Port Group
fc1/1 ext8 PortGroup 1
Ta b l e 1-6 Port Mapping Between the Cisco MDS 9000 Family and the Cisco Fabric Switch for
IBM BladeCenter
Cisco MDS 9000 Family Port
Cisco Fabric Switch for IBM
BladeCenter Port
Port Group
fc1/1 ext19 PortGroup 1
fc1/2 bay10
fc1/3 bay11
fc1/4 bay12
fc1/5 ext18 PortGroup 2
fc1/6 bay9
fc1/7 bay13
fc1/8 bay14
fc1/9 bay8 PortGroup 3
fc1/10 ext17
fc1/11 bay6
fc1/12 bay5
fc1/13 bay7 PortGroup 4
fc1/14 ext16
